KARL STORZ AIDA WD 300 4K System can be used on equipment carts or in integrated operating rooms and allows the recording and archiving of still images and video sequences in FULL HD, 3D and 4K quality. These can be placed in, e.g., OR reports.
The intelligent export manager provides considerable time savings as the recorded data is automatically saved in the background after each intervention.
The safety of the patients and the staff is the top priority in every OR – thanks to the integrated and freely configurable checklist. The security of the data is also guaranteed.
Combined with SCENARA®, a modular software solution, KARL STORZ offers the perfect solution for capturing, archiving, retrieving and managing image and video data.
The KARL STORZ AIDA WD 300 4K System is designed for use in the operating rooms of clinics and hospitals.
The KARL STORZ AIDA® WD 300 serves to aid the implementation and documentation of medical interventions aimed at examining and treating patients.
When performing medical interventions, the KARL STORZ AIDA® WD 300 can be used to do the following from the central touchscreen:
•Control non-medical devices;
•Transfer and display video and audio signals from the integrated signal sources to the integrated peripheral devices;
•Record, save, edit, forward and print medical examinations and interventions in the form of still images, video sequences and audio sequences
AIDA® offers the possibility to capture and store still images and video sequences in FULL HD, 4K and 3D quality. This standalone solution enables the comprehensive implementation of all documentation requirements arising in surgical procedures.
– AIDA® seamlessly fits into existing organizational structures – onto equipment carts, into integrated ORs and existing IT infrastructures (DICOM, HL7)
– AIDA® offers the possibility to record two image sources simultaneously
– AIDA® improves safety thanks to an integrated and freely configurable safety checklist
– AIDA® reduces turnover time due to the Intelligent Export Manager with automated data storage in the background
– AIDA® in combination with SCENARA® provides a complete solution for image and video management inside and outside the OR
KARL STORZ AIDA WD 300 4K System Technical data :
Input voltage: 100 VAC – 240 VAC
Input frequency: 50 Hz – 60 Hz
Power consumption max.:5 – 2 A
Dimensions (mm): 305 x 74.5 x 355 (W x H x D)
Weight max.: 6.0 kg
Degree of protection against electric shock:Class I
Degree of protection against humidity:IPX0
Hard drive capacity:2 TB
CPU:Intel® CoreTM [email protected] GHz
Operating system:Windows 10 IoT Enterprise
Mode of operation:Continuous
